Features
- Retrofits with existing one inch strobe tube cutouts in headlight, taillight or corner lights in all types of commercial vehicles
- Optional cruise mode reduces light output to 20% brightness
- Use with optional bezels to surface mount to any flat area on the vehicle body for additional lighting
Tech Specs
Input Voltage Range
9-32 Vdc
Operating Temperature
-40° C to +65° C / -40° F to +149° F
LED Options
Single or split colors: 6 LEDs
LED Colors Available
Amber, Blue, Green, Red, White
Flash Patterns
15
Light Sync
Up to 24 lightheads (Sync 2)
Dimensions
Insert: 1.5″ diameter x 0.9” depth (3.8 cm DIA x 2.3 cm D)
Bezel: 2.2” diameter x 1.65″ depth (5.6 cm DIA x 4.2 cm D)
Certifications*
SAE J595, ECE R10
*Valid when using compliant patterns, color configurations and active modules
Current Consumption
<1 amp/module
